1. Remove upholstery tool from holder and unwrap flex hose completely
2. Twist the Quick Release™ cord wrap clockwise to unwrap the power cord completely and plug into grounded outlet.

1. Remove tank from the back of the machine by lifting up tank carry handle.
NOTE: This tank was designed with a flat bottom so it can be easily filled.
2. Unscrew the black cap and remove bottle insert.
3. Fill tank with hot tap water to the water fill line. Add two ounces (1/4 cup) of BISSELL formula to the tank.
4. Replace the bottle insert in the tank and tighten the black cap. Replace the tank on the portable machine.

IMPORTANT! If using to clean upholstery, check upholstery tags. Check manufacturer’s tag before cleaning. “W” or “WS” on the tag means that you can clean this with a spot cleaner. If the tag is coded with an “X” or an “S”(with a diagonal stripe through it), or says “Dry Clean Only”, do not proceed with any deep cleaning machine. Do not use on velvet or silk. If manufacturer’s tag is missing or not coded, check with your furniture dealer.

1. Hold the tool approximately 1″ above the soiled surface. Press the spray trigger to apply the
cleaning solution to the soiled area.

NOTE: Hold end of hose below the tank water level to help prime the portable spot cleaner.

2. Using the brush on the tool, gently scrub the area to be cleaned.

3. Apply downward pressure on the tool and pull it toward you. The suction will remove the dirt and cleaning solution. Continue until no more dirt can be removed.

1. Empty the dirty tank when dirty water reaches the “FULL” line on the tank.
2. Remove dirty water tank and carry to a utility sink, toilet, or outside to dispose of dirty water.
3. To unlock the dirty tank lid, rotate handle over
the back of the tank. Remove lid and pour out dirty water. Rinse out dirty tank to remove any debris.
4. Replace top of tank, and rotate the handle forward to lock in place on front of tank.
5. Before replacing tank on machine, wipe debris from red filter.

1. Remove upholstery tool by pressing the small black button on top and pulling tool away from hose. Rinse tool in clean running water. Reattach tool when dry.
2. Suction clean water to rinse the hose. While machine is still running, lift end of hose and stretch to ensure all water is cleared from hose.
3. Coil flex hose around the hose wrap and secure upholstery tool in holder.
4. Remove, empty, rinse, and air dry both the Formula & Clean Water tank and the Dirty Water tank. After drying, replace tanks on machine.
NOTE: Store in a protected, dry area. Since this product uses water, it must not be stored where there is a danger of freezing. Freezing will damage internal components and void the warranty.
